Product Details:
|
| Model Number: | BIT-MSE-8K-208HD | Place Of Origin: | China |
|---|---|---|---|
| Brand Name: | Bitvisus | Function: | Video Splicer |
| Customization: | OEM.ODM | Package: | Equipment *1, Power *1, Certificate *1, Warranty Card *1 |
| Input Interface: | 2CH HDMI 2.0/DP 1.2 (either One) | Maximum Resolution Support: | 15360x1200@60hz |
| Warranty: | 12 Months | Supports: | Audio And Video Synchronization |
| Highlight: | 4K Video Switcher Controller,2X4 Video Switcher Controller,HDMI TV Video Wall Processor |
||
Ultra-High Definition Visuals:
Supports resolutions up to 7680x2400@60Hz, delivering crisp and vivid visuals for unparalleled viewing experiences.
Versatile Splitting Modes:
Offers a wide range of splitting modes including 1x1 to 2x4, ensuring ultimate flexibility for tailored multi-screen setups.
Point-to-Point Display Technology:
Maintains image integrity across multiple screens without stretching or deformation.
Industrial-Grade Design:
Features a thickened 4-layer PCB board with 16KV anti-static ability, ensuring long-term stability and reliability.
Energy Efficiency:
Designed with low power consumption and internal conduction cooling, eliminating the need for external cooling measures.
Seamless Audio & Video Synchronization:
Ensures perfect audio and video transmission sync for a truly immersive experience.
Advanced Processing Capabilities:
Powered by a 45nm high-end programmable FPGA chip, providing ultra-fast processing speed for real-time performance.
Wide Compatibility:
Accepts inputs from HDMI 2.0 or DP 1.2 sources, ensuring compatibility with most modern graphics cards and devices.
Customizable Resolution Settings:
Allows for customized resolution settings, including 7680x1200@60Hz and 7680x1200@30Hz, tailored to your specific needs.
Ease of Use:
Simple connection and setup process, suitable for both professionals and enthusiasts.
Extensive Accessories Included:
Comes with a 12V/2A power supply, HDMI/DP cables, conformity certificate, and warranty card.
| Diethylammonium chloride | BIT-MSE-8K-208HD | |
| importation | input interface | 2CH HDMI 2.0/DP 1.2 (either one) |
| HDCP function | Supports HDCP 2.2 | |
| transmission distance | ≤5 meters | |
| Input Maximum Pixel Clock | 600MHz | |
| Input single port resolution |
7680x1080@60Hz/7680x1200@60Hz (resolution within 4Kx2K@60Hz bandwidth) |
|
| Input color format | RGB888, 24bit | |
| exports | output interface | 8CH HDMI 1.3 |
| transmission distance | ≤15 meters | |
| Output Maximum Pixel Clock | 165M | |
| Output single port resolution |
1920x1200@60Hz 1280x800@60Hz (backward compatible, customizable) |
|
| Output Color Format | RGB888, 24bit | |
| sound frequency | audio output | 3.5mm audio jack (audio split) |
| norm | electric power source | DC 12V/2A |
| Maximum power consumption | 22W | |
| Storage/working temperature | -10 to 50ºC/0 to 50ºC | |
| Product Size | L290mm*W143mm*H22mm | |
| Packing weight (net weight of equipment) | 1.3KG | |
| List of accessories | 12V/2A Power Supply*1, HDMI/DP Cable*2, Certificate of Conformity*1, Warranty Card*1 | |
| (sth. or sb) else | after-sales service | Warranty 3 years |
