HDMI Video Wall Processor 1x4 2x4 1x8 4K Video Wall Controller

High Quality Video Wall Processor 2x4 1x8 1x4 HDMI 4k Video Wall Controller

High Quality Video Wall Processor 2x4 1x8 1x4 HDMI 4k Video Wall Controller specificities

Super high resolution, the output supports a maximum resolution of 7680x1200 @ 30Hz / 1920x4800 @ 30Hz, which is backward compatible with low resolution.
Support 1xN, Nx1, MxN and 90 ° rotation ratio stitching, without stretching, deformation, and wider field of vision.
Adopt high-end programmable FPGA chip with 45nm technology, full hardware real-time processing architecture, ultra fast processing speed without delay.
Industrial-grade design, thickened 6-layer PCB board, 16KV super strong anti-static ability, super product stability.
Support parallel operation to meet the real-time display requirements of large screen.
Low power consumption, energy saving and environmental protection design. Conductive heat dissipation is used inside without any external heat dissipation measures.

High Quality Video Wall Processor 2x4 1x8 1x4 HDMI 4k Video Wall Controller appliance

Common application includesUltra-high-resolution desktop applications, large screen walls, command and dispatch systems,multi-screen video surveillance, engineering display applications, multi-channel projection, VR, ring screen theaters, large advertising walls, LCD / LED multi-screen, etc.

High Quality Video Wall Processor 2x4 1x8 1x4 HDMI 4k Video Wall Controller Specification

Product name	BIT-MSE-4K60-104PRO
Input Max. Pixel FPS	600MHz
Output Max. Pixel FPS	330MHz
Input type	HDMI or DP (choose one, HDMI priority)
Output type	4 HDMI
3 screens support typical resolution	3x1920x1200@60Hz 3x1920x1080@60Hz 3x1280x800@60Hz 3x1024x768@60Hz
4 screens support typical resolution	4x1920x1200@60Hz 4x1920x1080@60Hz 4x1280x800@60Hz 4x1024x768@60Hz
Product factory default resolution	3840x2160@60Hz
2x2 Max supported resolution	3840x2400@60Hz
3x1/1x3Max supported resolution	1920x3600@60Hz/5760x1200@60Hz
4x1/1x4Max supported resolution	1920x4800@60Hz/7680x1200@60Hz
Output distance	15 meters
power supply	12V@2A AC-DC
Warranty	One year
